Drawing a simple walking-talking Android

The task is to draw a simple figure built from cylinders, spheres and disks. We will make the man walk and talk. The structure of the program is allmost identical to the structure in the module Horse

We plan the Android man like this:

The main body is a cylinder with a disk at each end
Both arms and both legs are cylinders with a sphere at each end
The head is a half sphere. This is solved with a clipping-plane, see code below
The eyes are partly hidden spheres
The "pins" are partly hidden cylinders

The complete class for the Android, oneMan:

/*
 * BS june 2011
 */
package and;
import javax.media.opengl.GL;
import javax.media.opengl.glu.GLU;
import javax.media.opengl.glu.GLUquadric;

/**
 *
 * @author Administrator
 */
public class oneMan
{
    // static dimensions
    private static final float BODY_LENGTH=3.0f;
    private static final float BODY_RADIUS=1.5f;
    private static final float LIMB_LENGTH=1.7f;
    private static final float LIMB_RADIUS=0.4f;
    private static final float HORN_LENGTH=0.6f;
    private static final float HORN_RADIUS=0.1f;

    // drawing precision
    private static final int SLICES=30;
    private static final int STACKS=30;

    // animation
    private static  float ARM_SWING=0.0f;
    private static  float DELTA_ARM_SWING=5.0f;
    private static  float MAX_ARM_SWING=50.0f;

    private static  float TALK_SWING=0.0f;
    private static  float MAX_TALK_SWING=5.0f;
    private static  float DELTA_TALK_SWING=2.0f;
    public oneMan()
    {

    }
    public void drawMe(GL gl)
    {
        // assume origo in bodys center.
        // x:forward, y:twds horses left, z:up
        GLU glu=new GLU();
        GLUquadric q=glu.gluNewQuadric();
        glu.gluQuadricDrawStyle(q, GLU.GLU_FILL);

        //glu.gluQuadricDrawStyle(q, GLU.GLU_SILHOUETTE);
        glu.gluQuadricOrientation(q, GLU.GLU_OUTSIDE);
        glu.gluQuadricNormals(q, GLU.GLU_SMOOTH);
        // set the material
        setGreenMaterial(gl);


        //---------------------------
        // draw body
        gl.glPushMatrix();
        glu.gluCylinder(q, BODY_RADIUS, BODY_RADIUS, BODY_LENGTH, SLICES, STACKS);
        glu.gluDisk(q, 0.0f, BODY_RADIUS, SLICES, STACKS);
        gl.glTranslatef(0.0f, 0.0f, BODY_LENGTH);
        glu.gluDisk(q, 0.0f, BODY_RADIUS, SLICES, STACKS);

        // draw head top
        // talk
        gl.glRotatef(TALK_SWING, 1.0f, 0.0f, 0.0f);
        gl.glTranslatef(0.0f, 0.0f, 0.07f+0.05f*TALK_SWING);
        glu.gluDisk(q, 0.0f, BODY_RADIUS, SLICES, STACKS);

        // halfsphere
        double[] cutplane=new double[]{0.0f,0.0f,1.0f,0.0f};
        gl.glClipPlane(GL.GL_CLIP_PLANE2,cutplane,0);
        gl.glEnable(GL.GL_CLIP_PLANE2);
        glu.gluSphere(q, BODY_RADIUS, SLICES, STACKS);

        gl.glDisable(GL.GL_CLIP_PLANE2);

         //horn
        drawHorn(gl,glu,q);

        // eyes
        setBlackMaterial(gl);
        drawEyes(gl,glu,q);
        setGreenMaterial(gl);

        // Draw arms
        gl.glPopMatrix();
        gl.glPushMatrix();
        gl.glTranslatef(BODY_RADIUS+LIMB_RADIUS+0.1f, 0.0f, BODY_LENGTH-LIMB_RADIUS);

        drawLimb(gl,glu,q,-ARM_SWING);

        gl.glPopMatrix();
        gl.glPushMatrix();
        gl.glTranslatef(-(BODY_RADIUS+LIMB_RADIUS+0.1f), 0.0f, BODY_LENGTH-LIMB_RADIUS);

        drawLimb(gl,glu,q,ARM_SWING);

        // Draw legs
        gl.glPopMatrix();
        gl.glPushMatrix();
        gl.glTranslatef(BODY_RADIUS-LIMB_RADIUS*2.0f, 0.0f, 0.2f);

        drawLimb(gl,glu,q,ARM_SWING);


        gl.glPopMatrix();
        gl.glPushMatrix();
        gl.glTranslatef(-(BODY_RADIUS-LIMB_RADIUS*2.0f), 0.0f, 0.2f);

        drawLimb(gl,glu,q,-ARM_SWING);

        gl.glPopMatrix();

        // delete the quadric
        glu.gluDeleteQuadric(q);
    }

    private void drawLimb(GL gl,GLU glu,GLUquadric q,float swing)
    {
        // arm or leg
        gl.glPushMatrix();
        gl.glRotatef(swing,1.0f,0.0f,0.0f);
        glu.gluSphere(q, LIMB_RADIUS, SLICES, STACKS);
        gl.glPopMatrix();
        gl.glPushMatrix();
        gl.glRotatef(180.0f+swing,1.0f,0.0f,0.0f);
        glu.gluCylinder(q, LIMB_RADIUS, LIMB_RADIUS, LIMB_LENGTH, SLICES, STACKS);
        gl.glTranslated(0.0f, 0.0f, LIMB_LENGTH);
        glu.gluSphere(q, LIMB_RADIUS, SLICES, STACKS);
        gl.glPopMatrix();
    }

    private void drawEyes(GL gl,GLU glu,GLUquadric q)
    {
        gl.glPushMatrix();
        gl.glRotatef(-20.0f,1.0f,0.0f,0.0f);
        gl.glRotatef(70.0f,0.0f,1.0f,1.0f);
        gl.glTranslated(0.0f, 0.0f, BODY_RADIUS -0.8f*LIMB_RADIUS);
        glu.gluSphere(q, LIMB_RADIUS, SLICES, STACKS);
        gl.glPopMatrix();
        gl.glPushMatrix();
        gl.glRotatef(-20.0f,1.0f,0.0f,0.0f);
        gl.glRotatef(-70.0f,0.0f,1.0f,1.0f);
        gl.glTranslated(0.0f, 0.0f, BODY_RADIUS -0.8f*LIMB_RADIUS);
        glu.gluSphere(q, LIMB_RADIUS, SLICES, STACKS);
        gl.glPopMatrix();
        gl.glPopMatrix();
    }
    private void drawHorn(GL gl,GLU glu,GLUquadric q)
    {
        gl.glPushMatrix();
        gl.glRotatef(10.0f,1.0f,0.0f,0.0f);
        gl.glRotatef(30.0f,0.0f,1.0f,1.0f);
        gl.glTranslatef(0.0f, 0.0f, BODY_RADIUS-0.1f);
        glu.gluCylinder(q, HORN_RADIUS, HORN_RADIUS, HORN_LENGTH, SLICES, STACKS);
        gl.glPopMatrix();
        gl.glPushMatrix();
        gl.glRotatef(10.0f,1.0f,0.0f,0.0f);
        gl.glRotatef(-30.0f,0.0f,1.0f,1.0f);
        gl.glTranslatef(0.0f, 0.0f, BODY_RADIUS-0.1f);
        glu.gluCylinder(q, HORN_RADIUS, HORN_RADIUS, HORN_LENGTH, SLICES, STACKS);
        gl.glPopMatrix();
    }

    public void setGreenMaterial(GL gl)
    {
        //Emaraldish
        float amb[]={0.0215f, 0.1745f, 0.0215f, 0.55f };
        float diff[]={0.07568f, 0.61424f, 0.07568f, 0.55f};
        float spec[]={0.633f, 0.727811f, 0.633f, 0.55f};
        float shine=76.8f;
        gl.glMaterialfv(GL.GL_FRONT_AND_BACK,GL.GL_AMBIENT,amb,0);
        gl.glMaterialfv(GL.GL_FRONT_AND_BACK,GL.GL_DIFFUSE,diff,0);
        gl.glMaterialfv(GL.GL_FRONT_AND_BACK,GL.GL_SPECULAR,spec,0);
        gl.glMaterialf(GL.GL_FRONT_AND_BACK,GL.GL_SHININESS,shine);
    }

    public void setBlackMaterial(GL gl)
    {
        //black plastic
        float amb[]={0.0f, 0.0f, 0.0f, 1.0f};
        float diff[]={0.01f, 0.01f, 0.01f, 1.0f};
        float spec[]={0.50f, 0.50f, 0.50f, 1.0f };
        float shine=32.0f;
        gl.glMaterialfv(GL.GL_FRONT_AND_BACK,GL.GL_AMBIENT,amb,0);
        gl.glMaterialfv(GL.GL_FRONT_AND_BACK,GL.GL_DIFFUSE,diff,0);
        gl.glMaterialfv(GL.GL_FRONT_AND_BACK,GL.GL_SPECULAR,spec,0);
        gl.glMaterialf(GL.GL_FRONT_AND_BACK,GL.GL_SHININESS,shine);
    }
    public void updateAngles(boolean walk, boolean talk)
    {
        if(walk)
        {
            ARM_SWING+=DELTA_ARM_SWING;
            if((ARM_SWING > MAX_ARM_SWING)||(ARM_SWING < - MAX_ARM_SWING))
                DELTA_ARM_SWING = -DELTA_ARM_SWING;
        }

        if(talk)
        {
            TALK_SWING+=DELTA_TALK_SWING;
            if((TALK_SWING > MAX_TALK_SWING) ||(TALK_SWING < 0 ))
                DELTA_TALK_SWING = -DELTA_TALK_SWING;
        }
    }
}

It should be rather straight-forward to implement variations of the android man or to implement a group of them, marching or playing.

References

The program project: https://svn.hiof.no/svn/psource/JOGL/Androidman
